Motorized Bending Testing Machine

Model GW-40A/50A
Description:
GW-A series motorized bending testing machines are special equipment for bending test on reinforce bar, steel bar and pipe etc. The motorized bending testing machine can do bending test in both directions according to the standard requirement. The motorized bending tester conforms to standards including ASTM A615, ASTM A615M, ISO 7438, and ISO8491 (E) etc.

Applied Standard

Motorized bending testing machines are special equipment for bending test on reinforce bar, steel bar and pipe etc. The motorized bending tester can do bending test in both directions according to the standard requirement.




Load Frame

Superior Load Frame Design

Specification

ModelGW-40AGW-50A
Diameter range of bars & pipes (mm)Ф6~40Ф8~50  6-50
Bending angle-positive direction(°) 0~180° (the angle can be set freely in the range)
Bending angle-reverse direction(°)0~25 (the angle can be set freely in the range) 0-180°
Rotating speed (r/min)          ≤2r/min
Diameter of driving tray (mm)Ф580   620Ф860   800
Power of motor(kW)1.5   2.33   3.8
Dimension of the unit (mm)1200×1000×9601010*790*12001460×1200×12001400*1100*1200
Weight(kg)1000   8501700   2000
